Crane Tongs and Clamps

9 Durable Drum Lifting Clamps/Tongs: Ensure Safe Handling of Steel and Plastic Drums

We can offer an extensive range of drum lifting tongs to suit steel and plastic drums. There is a range of drum lifting clamp models to choose from, which handle the drums horizontally or vertically.

Vertical drum clamp lifters (three-point)

Load capacity: 750kg
Weight: 9kg
Material: Alloy steel
Maximum opening: 61cm
Applicable range: Iron pipes, plastic barrels, open-top barrels

Vertical drum lifter clamps (three-point)

Load capacity: 750kg
Weight: 8kg
Material: Alloy steel
Maximum opening: 61cm
Applicable range: Iron pipes, plastic barrels, open-top barrels

Plastic drum clamps

Load capacity: 300kg
Weight: 7.5kg
Material: Alloy steel
Chain material: Grade 8.0 lifting chain
Inner diameter of lifting ring: 4.5cm
Chain length: 25cm

Vertical oil drum lifting clamps

Load capacity: 300kg
Weight: 5.2kg
Material: Alloy steel
Inner diameter of lifting ring: 6cm (height) * 4cm (width)
Applicable range: Iron barrels, plastic barrels

Vertical barrel lifting clamps

Rated load: 0.6t
Usage: Lifting and unloading upright cylindrical barrels (oil drums)
Material: Shougang low-carbon high-quality alloy steel
Features: Suitable for lifting steel oil drums and plastic barrels with fixed rings, can be used for both vertical and horizontal lifting of barrels.

YQC Vertical drum grabber clamps

Rated load: 0.6t
Material: High-quality low-carbon alloy steel
Features: Cast steel integrated central shaft, making it stronger and more durable. Effectively corrects the vertical alignment of the barrel, ensuring the oil drum remains level and vertical without tilting.

Manual horizontal drum tongs

Rated load: 500kg
Dimensions: 670*80
Net weight: 4kg

Semi-automatic horizontal drum tongs

Applicable range: Steel oil drums or plastic barrels with fixed rings
Rated load: 500kg
Net weight: 7.6kg

Vertical oil drum clamps

Rated load: 0.6t
Jaw width: 550-600mm
Net weight: 5kg

Application Gallery

垂直筒式提升机夹钳升降装置 — Vertical barrel hoist clamp lifters

Vertical oil drum clamps.jpeg — Vertical oil drum clamps

Precautions for Using the Drum Lifting Clamps

Apply a small amount of light mechanical lubricant to all moving parts to ensure safe and reliable operation.
Confirm that the drum’s weight and contents do not exceed the load capacity of the drum lifting clamp.
When lifting the drum, lift it smoothly and avoid lifting too quickly. During the lifting process, do not allow the drum to collide with other objects.
When lowering the drum, place it down gently to avoid damaging the drum.
Ensure that the clamp lifts and lowers the drum vertically.

Maintenance of the Drum Lifting Tongs

Apply light lubricant to the moving parts of the drum lifting clamp every 10-15 days.
Keep all parts of the drum lifting clamp clean. If there is any debris or dirt, clean it thoroughly to extend its service life.
Regularly check whether the springs and pins of the drum lifting clamp are in their normal positions.
