Zautomatyzowany dźwig do transportu kontenerów na sprzedaż

Name: Automated Container Straddle Carriers Crane for Sale
Brand: KSCRANE
Availability: InStock

The automated container straddle carrier crane is suitable for ports and terminals, transporting containers from the front line to the yard, or handling and loading/unloading containers within the yard. Current straddle carriers come in various sizes, ranging from mini straddle carriers to 4 high straddle carriers.

The design, manufacturing, and inspection of the Kuangshan Crane straddle container lifter comply with the latest domestic and international standards, including FEM, DIN, IEC, AWS, and GB. The port straddle carrier features straight driving, oblique driving, Ackermann steering, and other functions, and is equipped with comprehensive safety indicators and overload protection devices to maximize the safety of operators and equipment.

Zautomatyzowany dźwig do transportu kontenerów na sprzedaż

Container Straddle Carriers Crane Parameter

Container Straddle Crane Main Technical Data
Rated Lifting Capacity(t)		35	41
Base Distance(m)		6.5	7
Inner Width/Outer Width(m)		3.5/5.5	3.5/6
Lifting Height(m)		9.5/12.2	9.5/12.2
Stack Layers		2/3	2/3
Container Specification		20’, 40′	20’, 40′
Speed	Hoisting(Full Load/Empty Load)(m/min)	15/25	15/25
Speed	Gantry Traveling(Full Load/Empty Load)(km/m)	15/20	15/20
Spreader	Rotation	±5°	±5°
Spreader	Translation	±200mm	±200mm
Outer Turning Diameter of Wheel(m)		9.5	10
Wheel Numbers		4	8
Drive Mode		Electric Drive	Electric Drive
Brake Mode		Electrohydraulic	Electrohydraulic
Installed Power		~270kW	~300kW
Maximum Wheel Load(kN)		220KN	180KN
Power Supply		Diesel Generator Set, Batteries

Container Straddle Carriers Crane Features

Henan Kuangshan Crane offers straddle carriers with various power combination options, including electric straddle carriers and hybrid straddle carriers (diesel generator sets, low-power generator sets + batteries, batteries + hydraulic station), which are energy-saving and environmentally friendly.
Various steering functions, including straight driving, oblique driving, and Ackermann steering.
CMS intelligent service management system for real-time monitoring of equipment operating status.
Vector frequency conversion and torque balance control technology, which is energy-saving, environmentally friendly, convenient, and efficient.
Automated fault detection and real-time data display technology, ensuring safety and reliability.
Unique deviation correction and fine-tuning technology for large vehicles, braking shock absorption energy storage system, and anti-overturn design for lifting.
Humanized, personalized panoramic driver’s cabin with comfortable steering wheel operation and wide field of vision.
Comprehensive safety measures, including high wind alarms and dynamic safety scanning.

Services

Kuangshan Crane has over 20 years of extensive experience in manufacturing and exporting container straddle carrier cranes, offering necessary spare parts and professional installation and maintenance guidance services for all container straddle carrier cranes.

Spare Parts
We will prepare the required spare parts for your container straddle carrier crane for container handling so that any damaged or lost parts can be promptly replaced, reducing maintenance downtime and improving production efficiency.
Installation
We provide detailed video installation procedures of the container handling suwnica, and if needed, we can also offer remote video guidance.
Maintenance
We provide detailed maintenance instructions and offer free consultation services for any issues that may arise during the shipping container gantry crane’s usage period.

Kuangshan Crane is a container straddle carrier manufacturer. We have high-quality and cost-effective container straddle carriers for sale. Contact us to get your straddle carrier dimension pictures and the latest container straddle carrier price.
