Derek Overhead Offset Girder Tunggal LDP: Maksimalkan Ketinggian Bengkel dengan Desain Cerdas

Derek overhead offset girder tunggal elektrik LDP termasuk derek ringan dengan ruang kepala sangat rendah, kerekan elektrik terletak di sisi girder utama, yang meningkatkan ruang kerja kait dan dapat mengurangi tinggi dan biaya pabrik. Cocok untuk tempat dengan ruang kepala rendah di bengkel dan pabrik.

• Span: 7.5~22.5m(non-standard design is available according to customer’s requirement).
• Working class: A3
• Working Environment: Temperature -20℃～+40

Single Beam Offset Bridge Crane Structure

Single girder offset overhead crane consists of a box-shaped main beam welded by steel plate, end beam, trolley, and running mechanism, the trolley consists of a running end beam, trolley frame, and stationary electric hoist, adopting the form of bias hanging, running on the side of the main beam, the trolley is equipped with upper and lower horizontal wheels, and the vertical walking wheel is arranged in three points. The position of the electric hoist is elevated from the traditional under the main beam to the upper side of the main beam, which effectively improves the lifting height.

• The trolley runs as a cone-type motor brake, open gear drive.
• The main girder is box-type structure, off-rail, with horizontal wheels on the top and bottom, which is safe and reliable and prevents the gnawing of rails.
• The trolley is driven by conical motor braking and open gear transmission. Running motor can be selected according to user requirements of soft start motor and frequency conversion speed control, crane start smoothly, safe and reliable operation.
• The operation mode is equipped with a ground handle or wireless remote control.

Single Girder Offset Overhead Crane Main Beam Internal Joint Robot Welding Line

• Dibandingkan dengan pekerjaan manual, lasan yang dibentuk oleh robot memiliki bentuk yang sangat baik, lebar lasan seragam, permukaan datar, dan cacat pada dasarnya nol.
• Karena lebar las yang seragam, kerusakan yang disebabkan oleh konsentrasi tegangan pada las sangat berkurang, dan tinggi las rata-rata lebih tinggi daripada las buatan, yang sangat meningkatkan kekuatan produk.

LDP Offset Overhead Crane VS LD Overhead Crane

LDP type electric single girder offset overhead crane is a girder crane with angular trolley structure. Compared with Derek overhead girder tunggal listrik tipe LD, it has better utilization of height space. This structure is often used in the case where the elevation of the trolley track in the workshop is low, but the headroom between the top surface of the track and the lowest point of the workshop is large. This structure can better utilize the height space inside the workshop, and can effectively raise the hoist lifting height.
